Disc Brake Conversion Parts
SWAP.2 1964-1973 Granada based front disc brake system parts
Note specific parts for 64-66 and 67-73 Mustang, will fit many 60's Ford vehicles.
Granada Type single piston caliper, corrosion protection coated. 7/16"-24 outlet. Sold as a left and right set only. New, no core charge.
P/N 406970 $59/set
Granada Type caliper brackets, includes grade 8 mounting bolts. Sold as a left and right set only.
P/N MCB.3 $85/set
1964-66 spec Granada type high strength alloy steel steering knuckles (spindles) , includes grade 8 mounting bolts. has 1964-66 correct steering and suspension geometry. Sold as a left and right set only.
P/N GKK.65 $179/set
1967-73 spec Granada type high strength alloy steel steering knuckles (spindles) , includes grade 8 mounting bolts. has 1967-73 correct steering and suspension geometry. Sold as a left and right set only.
P/N GKK.67 $179/set
1964-66 spec Granada type high strength alloy steel spindle kit. The kit includes knuckles, caliper brackets, a shield kit, and grade 8 mounting bolts. Has 1964-66 correct steering and suspension geometry. Sold as a left and right set only.
P/N GSK.65 $289/set
1967-73 spec Granada type high strength alloy steel spindle kit. The kit includes knuckles, caliper brackets, a shield kit, and grade 8 mounting bolts. Has 1967-73 correct steering and suspension geometry. Sold as a left and right set only.
P/N GSK.67 $289/set
Granada type front disc brake dust/splash shield set, semi-gloss black coating, also includes foam gaskets, mounting flanges, 6 mounting bolts, and threadlocker. Sold as a left and right set only.
P/N DBS.1 $59/set
Granada 11.06" front disc brake rotors. slotted. Sold as a left and right set only.
P/N 5419set $94/set
Granada type front disc brake wheel bearing and seals kit, 2 ea inner bearings, outer bearings, and wheel seal, no races. Sold as a left and right set only.
P/N BAS.2 $22/set
Granada type front wheel hardware kit, 2ea bearing washers, spindle nuts, nut retainers, cotter pins, dust caps.
P/N WHS.2 $15/set
Granada type front caliper hardware kit, 2ea support keys, support key spring, caliper retaining pins (bolts), and 2 ea anti-rattle clips.
P/N CHS.2 $15/set
1964-66 front disc brake hose set, 3/8" female inlet fitting 7/16" male outlet fitting, with mounting L brackets and moun ting hardware. Sold as a left and right set only.
P/N GR65 $24/set
1967-73 front disc brake hose set, 7/16" female inlet fitting 7/16" male outlet fitting with mounting L brackets and moun ting hardware. Sold as a left and right set only.
P/N GR67 $24/set
Granada type front disc brake pad set semi-metallic. Sold as a left and right set only.
P/N P91 $24/set
Adjustable proportioning valve, includes adapter fittings.
P/N APV.1 $28 each
OEM type combination proportioning valve. Includes adapter fittins and mounting nuts.
P/N $73 each
Manual type disc/drum master cylinder (new), includes adapter fitting and an adjustable pushrod.
P/N 11682A $59 each
Power type disc/drum master cylinder (new), includes an adapter fitting.
P/N 11680A $59 each
10 lbs residual pressure valve, includes adapter fittings.
P/N RPV.10 $10 each
Granada spindle to Mustang adapter outer tie rod set, manual 64-66 8 cylinder type, includes grease fittings, rubber grease boots, and cotter pins. Sold as a driver and passenger set only.
P/N TR.1 $24/set
Granada spindle to Mustang adapter outer tie rod set, manual 64-66 6 cylinder type, right hand threads, includes grease fittings, rubber grease boots, and cotter pins. Sold as a driver and passenger set only.
P/N TR.2 $36/set
Granada spindle to Mustang adapter outer tie rod, driver side power 64-66 8 cylinder type, includes grease fitting, rubber grease boot, and cotter pin. Driver side only.
P/N TR.3 $21 each
Granada spindle to Mustang adapter outer tie rod, driver side power 64-66 6 cylinder type, includes grease fitting, rubber grease boot, and cotter pin. Driver side only.
P/N TR.3 $27 each
Granada spindle to Mustang adapter outer tie rod set, power 64-66 8 cylinder type, includes grease fittings, rubber grease boots, and cotter pins. driver and passenger side.
P/N TR.5 $33/set
Granada spindle to Mustang adapter outer tie rod set, power 64-66 6 cylinder type, includes grease fittings, rubber grease boots, and cotter pins. driver and passenger side.
P/N TR.6 $39/set
